AC Charging Stations

AC charging stations enable electric and plug-in hybrid vehicles to be charged safely and efficiently using alternating current. They are an ideal charging solution for locations where vehicles remain parked for extended periods, including homes, residential complexes, workplaces, car parks, hotels and commercial facilities.

White Rose locally manufactured AC charging stations offer a range of power, connection and management options for different charging requirements. With 7.4 kW, 11 kW and 22 kW alternatives, they provide flexible solutions for applications ranging from individual home use to multi-vehicle commercial projects.

Key Features of AC Charging Stations

• 7.4 kW, 11 kW and 22 kW power options
• Compatibility with electric and plug-in hybrid vehicles
• Adjustable charging current
• AC and DC residual current protection
• Overtemperature and overvoltage protection
• Durable enclosure suitable for indoor and outdoor use
• Socketed and tethered cable model options
• Scheduled charging
• User authorisation and remote management options
• Solutions suitable for individual and commercial use

Features may vary depending on the selected model and configuration.

How Does an AC Charging Station Work?

An AC charging station safely and efficiently transfers alternating current from the electrical grid to an electric vehicle. The vehicle’s onboard charger converts this alternating current into the direct current required by the battery.

The actual charging rate depends on the charging station’s capacity, the vehicle’s maximum onboard AC charging rate, the available electrical infrastructure and the type of connection. For example, if a vehicle that supports a maximum AC charging rate of 11 kW is connected to a 22 kW charging station, the vehicle will charge at a maximum of 11 kW.

Charging Solutions Compatible with Electric Vehicles

Depending on the connection and configuration of the selected model, White Rose AC charging stations are compatible with electric and plug-in hybrid vehicles that use the Type 2 connector widely adopted throughout Europe.

The products are developed with consideration for the relevant standards applicable to electric vehicle charging systems. A technical site assessment is recommended before installation to determine the compatibility of the vehicle, electrical infrastructure and charging station.

Home AC Charging Stations

Home AC charging stations allow you to charge your electric vehicle safely and conveniently at your home or private garage. Charging the vehicle overnight or while it remains parked for an extended period reduces the need to rely on public charging points.

Compared with portable chargers or standard domestic sockets, fixed AC charging stations can offer controlled power delivery, user authorisation and enhanced electrical protection features.

Before installation, the electrical panel, available electrical capacity, earthing system and the vehicle’s maximum AC charging rate should be evaluated. White Rose offers tailored solutions covering product and power selection as well as installation planning.

AC Charging Stations for Residential Complexes

As electric vehicle ownership increases, the demand for charging infrastructure in apartment buildings, residential complexes and managed communities continues to grow. AC charging stations installed in shared car parks allow residents to charge their vehicles conveniently while parked.

Selecting the charging unit is only one part of a residential charging project. The available electrical capacity, cabling infrastructure, user authorisation, energy consumption monitoring and simultaneous charging of multiple vehicles must also be evaluated.

Depending on the project requirements, user identification, consumption monitoring, remote management and load management features can be incorporated into the system. This allows the available electrical capacity to be used efficiently and makes it easier to add more charging stations in a controlled manner.

AC Charging Stations for Workplaces and Office Buildings

Workplaces, factories, office buildings and corporate car parks are suitable locations for AC charging stations because vehicles generally remain parked for extended periods. Employees, managers and visitors can charge their electric vehicles during working hours.

Depending on the organisation’s requirements, charging can be provided free of charge, restricted to authorised users or billed according to energy consumption. User authorisation and remote management features allow charging station access and charging sessions to be monitored and controlled.

White Rose provides project-based solutions covering capacity analysis, product selection, charging station positioning, electrical infrastructure planning and system management.

AC Charging Solutions for Fleets

Effective charging management is essential for company vehicles, rental fleets, service vehicles and other commercial electric vehicle fleets. Controlled charging outside operational hours helps ensure that vehicles are ready for their scheduled daily use.

Fleet charging projects should consider the number of vehicles, parking duration, daily energy requirements, available grid capacity and the maximum AC charging rate supported by each vehicle. In projects with multiple charging stations, load management can distribute the available power across the stations efficiently.

White Rose develops scalable AC charging solutions for applications ranging from small vehicle groups to large commercial fleets.

AC Charging Stations for Hotels and Commercial Facilities

Hotels, shopping centres, restaurants, car park operators and other commercial facilities can expand their range of services by offering electric vehicle charging to their customers and visitors.

AC charging stations are particularly suitable for locations where vehicles remain parked for a reasonable period. Depending on the business model, charging can be offered as a complimentary customer service or provided as a paid service.

White Rose supports commercial projects in product selection, power planning, charging station positioning, user management and the identification of suitable software infrastructure.

What Should Be Considered When Selecting an AC Charging Station?

The maximum output of the charging station should not be the only consideration when selecting an AC charging solution. The following factors should be evaluated together:

• The vehicle’s maximum supported AC charging rate
• Whether the electrical installation is single-phase or three-phase
• Available connection and contracted power
• The need for 7.4 kW, 11 kW or 22 kW charging
• Preference for a socketed or tethered model
• Indoor or outdoor installation conditions
• User authorisation requirements
• Remote monitoring and management features
• Load management requirements for multiple charging stations
• Electrical protection and earthing infrastructure

Selecting the correct product and infrastructure is essential for safe operation, efficient charging and the future expansion of the charging system.

Why Choose White Rose AC Charging Stations?

White Rose develops locally manufactured AC charging stations for a wide range of electric vehicle charging requirements. Its product and project solutions are suitable for applications including homes, residential complexes, workplaces, hotels, commercial facilities and vehicle fleets.

Contact White Rose to identify the most suitable AC charging station for your requirements, obtain detailed technical information or request a tailored solution for your project.
